KEB COMBIVERT F5 Series Installation Guide & Operation Manual

41
6. Quick Reference
Display Parameter Adjust. range Resolution Cust. setting
CP. 0 Password input 0...9999 1 read only
CP. 1 Actual frequency display – 0.0125 Hz read only
CP. 2 Set frequency display – 0.0125 Hz read only
CP. 3 Inverter status display – – read only
CP. 4 Phase current – 0.1 A read only
CP. 5 Phase current, Peak value – 0.1 A read only
CP. 6 Actual load – 1 % read only
CP. 7 Actual DC voltage – 1 V read only
CP. 8 Actual DC voltage, Peak value – 1 V read only
CP. 9 Output voltage – 1 V read only
CP.10 Minimum frequency 0…400 Hz 0.0125 Hz ___________
CP.11 Maximum frequency 0…400 Hz 0.0125 Hz ___________
CP.12 Acceleration time 0.01…300.00 s 0.01 s ___________
CP.13 Deceleration time(-1 see CP.12) -1; 0.01…300.00 s 0.01 s ___________
CP.14 S-curve time 0.00 (off)…5.00 s 0.01 s ___________
CP.15 Torque boost 0.0…25.5 % 0.1 % ___________
CP.16 Rated frequency 0…400 Hz 0.0125 Hz ___________
CP.17
1)
Voltage stabilization 1…650 V (off) 1 V ___________
CP.18
1)
Carrier frequency 2/4/8/12/16 kHz – ___________
CP.19 Fixed frequency 1 -400...400 Hz 0.0125 Hz ___________
CP.20 Fixed frequency 2 -400...400 Hz 0.0125 Hz ___________
CP.21 Fixed frequency 3 -400...400 Hz 0.0125 Hz ___________
CP.22
1)
DC-braking, Mode 0…9 1 ___________
CP.23 DC-braking, Time 0.00…100.00 s 0.01 s ___________
CP.24 Max. ramp current 0…200 % 1 % ___________
CP.25 Max. constant current 0…200 % (off) 1 % ___________
CP.26
1)
Speed search condition 0…15 1 ___________
CP.27 Quick stop time 0.00…300.00 s 0.01 s ___________
CP.28 Response of ext. overtemperature 0…7 1 ___________
CP.29
1)
Analog output 1 0…12...20 {F5G} 1 ___________
CP.30 Analog output 1, Amplification -20.00…20.00 0.01 ___________
CP.31
1)
Relay output 1 0…58...66 {F5B} 1 ___________
CP.32
1)
Relay output 2 0…58...66 {F5B} 1 ___________
CP.33 Relay output 2, Switching level ±30000.00 0.01 ___________
CP.34
1)
Source of rotation direction 0…9 1 ___________
CP.35
1)
AN1 interface selection 0…2 1 ___________
CP.36 AN1 zero point hysteresis -10.0…10.0 % 0.1 % ___________

KEB COMBIVERT F5 Series Specifications

General

Control Method	Vector Control, V/f Control
Protection Class	IP20
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Communication Interfaces	CAN, PROFIBUS, Modbus RTU
Cooling Method	Fan Cooled
Relative Humidity	Up to 95% (non-condensing)
