KEB COMBIVERT F5 Series Installation Guide & Operation Manual

40
Error Diagnosis
E.CO1 ERROR counter overrun 1 54 Error: Counter overflow encoder channel 1
E.CO2 ERROR counter overrun 2 55 Error: Counter overflow encoder channel 2
E. BR ERROR brake 56 Error: This error can occur in the case of switched on brake cont-
rol, if the load is below the minimum load level Pn.58 (application
mode) at start up.
E.INI ERROR initialization MFC 57 Error: MFC not booted
E.HYBc ERROR hybrid changed 59 Error: Encoder interface identifier has changed, it must be confir-
med over ec.0 or ec.10 (application mode).
E.ccd ERROR calculation drive 60 Error: during the automatic motor stator resistance measurement
E.OS ERROR over speed 105 Error: Real frequency is bigger than the max. Output frequency
A.OHI ABN.STOP overheat int. 87 Warning: overtemperature in the interior
A.nOH no A. overheat pow.mod. 88 Warning: no more overtemperature of power module
A. OH A.STOP overheat pow.mod 89 Warning: Overtemperature of power module
A. EF ABN.STOP external fault 90 Warning: external error
A.ndOH no A. drive overheat 91 Warning: no more overtemperature of motor TEMPERATURE
SENSOR. Motor SENSOR is low-resistance again.
A.nOHI no A.STOP overheat int. 92 Warning: no more overtemperature in the interior
A.buS ABN.STOP bus 93 Warning: Watchdog for communication between operator/control
card has responded
A.PRF ABN.STOP prot. rot. for. 94 Warning: locked direction of rotation clockwise
A.PRR ABN.STOP prot. rot. rev. 95 Warning: locked direction of rotation counterclockwise
A.dOH ABN.STOP drive over heat 96 Warning: overtemperature of motor TEMPERATURE SENSOR
A.OH2 ABN.STOP motor protect. 97 Warning: electronic motor protective relay has tripped
A.nOL no ABN.STOP overload 98 Warning: no more overload, OL counter has reached 0 %.
A. OL ABN.STOP overload 99 Warning: Overload can only be reset at A.nOL, if OL counter has
again reached 0 %
A.OL2 ABN.STOP overload 2 100 Warning: Overload can only be reset at A.nOL2, if cool-down time
has elapsed
A.nOL2 no ABN.STOP overload 2 101 Warning: no more overload, the cool-down time has elapsed.
A.SET ABN.STOP set 102 Warning: set selection: It has been attempted to select a locked
parameter set.

KEB COMBIVERT F5 Series Specifications

General

Control Method	Vector Control, V/f Control
Protection Class	IP20
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overtemperature
Communication Interfaces	CAN, PROFIBUS, Modbus RTU
Cooling Method	Fan Cooled
Relative Humidity	Up to 95% (non-condensing)
