Parameter sets
© KEB, 2015-07 COMBIVERT R6-N Page3.7 - 3
3
10
3.7 Parameter sets
KEB COMBIVERT includes 8 parameter sets (0. .. 7), i.e., all programmable parameters are 8 times available
in the inverter and can be assigned independently with different values. Since many parameters in the param-
eter sets have the same values, it would be complicated to adjust each parameter individually in each set. This
section describes how to copy, lock and select entire parameter sets and to reinitialize the inverter.
3.7.1 Not set-programmable parameters
Certain parameters are not set-programmable, since their value must be the same in all sets (e.g. bus address
orbaudrate).Theparametersetnumberismissingintheparameteridenticationinorderthattheseparame-
ters are immediately visible.
Always the same value is valid for all non set-programmable parameters independent of the selected
parameter set!
Thefollowingparametersarenotset-programmable:
SY-Parameters ud.01...17
ru-Parameter Fr.02...04/ 07/ 09/ 11
di-Parameter An.41…52
In-Parameter(exception:In.24 and 25) LE.17-26
Pn.00...19, 31
3.7.2 Security-Parameters
The security parameters include the baud rate, inverter address, hour counter, control type, serial number/cus-
tomer number, trimming values, and fault diagnosis. It make sense that they are not overwritten when loading
the default set.
SY.02/ 03/ 06/ 07/ 11
ru.40/ 41
ud.01
Fr.01
In.10...16/ 24...30
3.7.3 Indirect and direct set-addressing
The parameter values are displayed and edited at indirect set-addressing, which of the set pointer (Fr.09) is
adjusted. Direct set-addressing allows the display or writing of a parameter value directly into one or more pa-
rameter sets independent of the set pointer. Direct set programming is only possible via bus operation.
