Special Functions

LE.17/ LE.22: Timer start input selection

Bit Value Input Terminal

0 1 ST (prog. input „control release/reset“) X2A.16

1 2 RST (prog. input „reset“) X2A.17

2 4 F (prog. input) X2A.14

3 8 R (prog. input) X2A.15

4 16 I1 (prog. input 1) X2A.10

5 32 I2 prog. input 2) X2A.11

6 64 I3 (prog. input 3) X2A.12

7 128 I4 (prog. input 4) X2A.13

8 256 IA (internal input A) no

9 512 IB (internal input B) no

10 1024 IC (internal input C) no

11 2048 ID (internal input D) no

Timer display (ru.43 / ru.44)

ru.43 / ru.44 displays the actual counter reading dependent on the adjusted clock source (LE.21 / 26). By writ-

ing on ru.43 / 44 the counter can be set to a value. If the clock source is changed during the running time the

counter content is maintained but is interpreted according to the new clock source.

Timer reset input selection (LE.19 / LE.24)

Theinputswhichresetthetimercanbedenedwiththefollowingtable. The individual inputs are OR-operated,

i.e.ifoneofthespeciedinputsistriggered,thetimerjumpsbacktozero.Ifastartingandresetconditionare

active simultaneously, reset has priority.

LE.19/ LE.24: Timer reset input selection
