KEB COMBIVERT R6-N User Manual

Page 3.8 - 6 COMBIVERT R6-N © KEB, 2015-07
Special Functions
Timer reset condition (LE.20 / LE.25)
Theconditionswhenthetimerisresetadditionallytotheinputscanbedenedinaccordancewiththefollowing
table. The individual conditions are OR-operated.
Bit No. Decimal value Condition
0 1 Modulation on
1 2 Modulation off
2 4 reserved
3 8 Change of parameter set
4 16 Power-On-Reset
Comparison level 0...7 (LE.00...LE.07)
LE.00...LE.07denethelevel for the switching conditions 37 / 38 („timer > level“). If the timer exceeds the
adjusted value the switching condition is set. A level in the range of -10.737.418,24 to 10.737.418,23 can be
adjusted. But only values of 0...655,35 are sensible for the counter.
3.8.2 Mask out inverter state (Pn.30)
Thefollowingtwofunctionsarecombinedinthisparameter:
pn.30
Bit Value Description
0
0 The state base-block is displayed in ru.00
1 The state base-block is not displayed in ru.00
1 0 Errors E.FnEt and E.nEt are always entered in the error history (In.24).
2 Errors E.FnEt and E.nEt are only entered in the error history (In.24) at control release.
3.8.3 Master / Slave input selection
With parameter Pn.31 the digital input can be selected with which the master / slave mode is activated.By de-
fault, no value is selected.
Pn.31: Input selection Master/Slave
Bit Value Description
4 16:I1 Digital input 1
5 32:I2 Digital input 2
6 64:I3 Digital input 3
