KEB COMBIVERT R6-N User Manual

Hardware
© KEB, 2015-07 COMBIVERT R6-N Page1.3 - 5
1
10
In order to prevent a malfunction caused by interference voltage supply on the control inputs, the following
directionsshouldbeobserved:
EMC
•
Use shielded/drilled cables
•
Lay shield on one side of the inverter onto earth potential
•
Lay control and power cable separately (about 10...20 cm apart); Lay crossings in a right angle
U
X2A
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
max. 25 mA DC
per digital output
Analog output
0…±10 V DC / 5 mA
max. 30 V DC
0.01…2 A
max. 30 V DC
0.01…2 A
Voltage supply of the
inputs
Control release
