KEB COMBIVERT R6-N User Manual

Parameter summary
© KEB, 2015-07 COMBIVERT R6-N Page3.1 - 5
3
10
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
LE.15 hysteresis 7 0D0Fh rw p --- 0,00 300,00 0,00 0.01 --- 3.4-14, 3.4-15
LE.17 timer 1 start inp. sel. 0D11h rw np E 0 4095 0 1 ---
3.2-10, 3.4-9, 3.7-3, 3.8-3,
3.8-4, 3.8-5
LE.18 timer 1 start condition 0D12h rw np E 0 15 0 1 --- 3.8-3, 3.8-4
LE.19 timer 1 start inp. sel. 0D13h rw np E 0 4095 0 1 --- 3.4-9, 3.8-3, 3.8-5
LE.20 timer 1 reset condition 0D14h rw np E 0 31 16 1 --- 3.8-3, 3.8-6
LE.21 timer 1 mode 0D15h rw np --- 0 63 0 1 --- 3.2-10, 3.8-3, 3.8-4, 3.8-5
LE.22 timer 2 start inp. sel. 0D16h rw np E 0 4095 0 1 ---
3.2-10, 3.4-9, 3.8-3, 3.8-4,
3.8-5
LE.23 timer 2 start condition 0D17h rw np E 0 15 0 1 --- 3.8-3, 3.8-4
LE.24 timer 2 start inp. sel. 0D18h rw np E 0 4095 0 1 --- 3.4-9, 3.8-3, 3.8-5
LE.25 timer 2 reset condition 0D19h rw np E 0 31 16 1 --- 3.8-3, 3.8-6
LE.26 timer 2 mode 0D1Ah rw np --- 0 63 0 1 --- 3.2-10, 3.8-3, 3.8-4
Pn.00 Auto retry E.OC E. UP 0400h rw np --- 0:off 1:on 1:on 1 --- 3.6-9, 3.7-3
Pn.02 Auto retry E.OC E. OC 0402h rw np --- 0:off 1:on 0:off 1 --- 3.6-10
Pn.03 E.EF stopping mode 0403h rw np --- 0 6 0 1 --- 3.6-6, 3.6-7, 3.6-8, 3.6-10
Pn.04 ext. fault input select 0404h rw np E 0 4095 64 1 --- 3.4-9, 3.6-6
Pn.05 Watchdog reaction 0405h rw np --- 0 6 6 1 ---
3.6-3, 3.6-6, 3.6-7, 3.6-8,
3.6-10
Pn.06 Watchdog time 0406h rw np E 0,00:off 60,00 0,00:off 0,01 s 3.6-6
Pn.08 Warning OL stop. mode 0408h rw np --- 0 6 6 1 --- 3.4-13, 3.6-5, 3.6-8, 3.6-10
Pn.09 OL warning level 0409h rw np --- 0 100 80 1 % 3.4-13, 3.6-5, 3.6-10
Pn.10 warning OH stop. mode 040Ah rw np --- 0 6 6 1 ---
3.4-13, 3.6-3, 3.6-5, 3.6-8,
3.6-10
Pn.11 OH warning level 040Bh rw np --- 0 variable 70 1 Degree 3.4-13, 3.6-3, 3.6-5, 3.6-10
pn.14 disconnecting time E.nEt 040Eh rw np --- 0,00 10,00 0,00 0,01 s 3.6-8, 3.6-10, 5.1-3
Pn.15 General fault reset 040Fh rw np --- 0 10 3 1 --- 3.6-2, 3.6-9
pn.16 Int. warning OH stop. mode 0410h rw np --- 0 6 0 1 --- 3.6-5, 3.6-8, 3.6-9, 3.6-10
Pn.17 Int. warning OH switch off time 0411h rw np --- 0 300 0 1 s 3.6-5
pn.18 E.Set stopping mode 0412h rw np --- 0 6 0 1 --- 3.6-6, 3.6-7, 3.6-8, 3.7-9
Pn.19 Operating mode 0413h rw np E 0 5 0 1 ---
3.4-3, 3.5-3, 3.6-10, 4.2-3,
4.2-4, 4.2-5
Pn.30
Fadeout of status- / error mes-
sages
0420h rw np E 0 3 0 1 --- 3.6.5-10
Pn.31 Input selection Master/Slave 041F rw np --- 0 112 0 1 ---
ru.00 Inverter state 0200h ro np --- 0 255 0 1 --- 3.2-5, 3.6-3
ru.01 Type 0201h ro np --- 0 6 0 1 --- 3.2-1, 3.2-4
ru.03 Actual mains frequency 0203h ro np --- -320,00 320,00 0,00 0,01 Hz
3.2-5, 3.3-3, 3.3-4, 3.9-6,
4.2-4
ru.08 AC-Phase current L1 0208h ro np --- 0,0 6553,5 0,0 0,1 A 3.2-5
ru.09 AC-Phase current L2 0209h ro np --- 0,0 6553,5 0,0 0,1 A 3.2-5
ru.10 AC-Phase current L3 020Ah ro np --- 0,0 6553,5 0,0 0,1 A 3.2-5
ru.11 Input voltage 020Bh ro np --- 0 1000 0 1 V 3.2-5
ru.13 Act. DC utilization 020Dh ro np --- 0 255 0 1 % 3.2-6
ru.14 Actual DC utilisation / peak value 020Eh rw np --- 0 255 0 1 % 3.2-6
ru.15 DC current 020Fh ro np --- 0,0 6553,5 0 0,1 A 3.2-6, 3.3-3, 3.3-4
ru.16 DC output current / peak value 0210h rw np --- 0,0 6553,5 0 0,1 A 3.2-6
ru.17 AC current 0211h ro np --- -3276,7 3276,7 0 0,1 A 3.2-6, 3.3-3, 3.3-4
ru.18 DC voltage / reference value 0212h ro np --- 0 1000 0 1 V
3.2-6, 3.3-3, 3.3-4, 3.5-4,
4.2-4
ru.19 DC output voltage 0213h ro np --- 0 1000 0 1 V 3.2-6, 3.2-7
ru.20 peak DC voltage 0214h rw np --- 0 778 0 1 V 3.2-7
ru.21 Input terminal state 0215h ro np --- 0 4095 0 1 --- 3.2-7, 3.4-2, 3.4-3, 3.4-5
ru.22 Internal input state 0216h ro np --- 0 4095 0 1 ---
3.2-7, 3.2-18, 3.4-2, 3.4-3,
3.4-5, 3.4-14
ru.23 Output condition state 0217h ro np --- 0 255 0 1 --- 3.2-8, 3.4-11, 3.4-12
ru.24 Stateofoutputags 0218h ro np --- 0 255 0 1 --- 3.2-8, 3.4-11, 3.4-12
ru.25 Output terminal state 0219h ro np --- 0 255 0 1 ---
3.2-9, 3.2-18, 3.4-2, 3.4-11,
3.4-12, 3.4-18, 7.1-4
ru.26 Active parameter set 021Ah ro np --- 0 7 0 1 --- 3.2-9
ru.33 ANOUT1 pre ampl. disp. 0221h ro np --- -400,0 400,0 0 0,1 % 3.2-9, 3.3-2, 3.3-4
ru.34 ANOUT1 post ampl. disp. 0222h ro np --- -100,0 100,0 0 0,1 % 3.2-9, 3.3-4, 3.4-14
ru.38 Power module temperature 0226h ro np --- 0 100 0 1 Degree 3.2-9, 3.3-3, 3.3-4, 3.4-13
ru.39 OL counter display 0227h ro np --- 0 100 0 1 % 3.2-10, 3.4-13, 3.6-5
ru.40 Power on counter 0228h rw np --- 0 65535 0 1 h 3.2-10, 3.7-3
ru.41 modulation on counter 0229h rw np --- 0 65535 0 1 h 3.2-10
ru.43 Timer 1 display 022Bh rw np --- 0 655,35 0 0,01 --- 3.2-10, 3.4-13, 3.8-3, 3.8-5
ru.44 Timer 2 display 022Ch rw np --- 0 655,35 0 0,01 --- 3.2-10, 3.4-13, 3.8-3, 3.8-5
ru.68 rated DC voltage 0244h ro np --- 0 1000 0 1 V 3.2-10
continued on the next page
