Parameter summary
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
ru.80 Digital output state 0250h ro np --- 0 255 0 1 ---
3.2-11, 3.2-17, 3.4-2, 3.4-
11, 3.4-12, 3.4-18
ru.81 Actual power 0251h ro np --- -3200,00 3200,00 0,00 0,01 kW
3.2-11, 3.3-3, 3.3-4, 3.4-14,
4.2-4, 4.2-5
ru.82 Total regen 0252h rw np --- 0 2147483647 0 1 KWh 3.2-11
ru.83 Total motor 0253h rw np --- 0 2147483647 0 1 KWh 3.2-11
ru.84 Total net 0254h rw np --- 0 2147483647 0 1 KWh 3.2-11
ru.85 actual net 0255h ro np --- 0,00 655,35 0 0,01 kVA 3.2-11
SY.02 Inverteridentier 0002h cp-ro np --- identier identier identier 1 hex 3.2-16, 3.7-3
SY.03 Power unit code 0003h cp-ro np E 0 32767 0 1 --- 3.2-16, 3.6-7, 5.1-5
SY.06 Inverter address 0006h rw np E 0 239 1 1 --- 3.2-16, 7.1-4
SY.07 baud Rate ext. bus / PC 0007h rw np E 0 6 3 1 --- 3.2-16
Sy.09 HSP5 watchdog time 0009h cp-ro np E 0,00:off 10,00 0,00:off 0,01 s 3.2-16, 3.6-6
SY.11 Baud rate int. bus 000Bh cp-ro np E 0 10 5 1 --- 3.2-17
SY.32 Scope timer 0020h ro np --- 0 65535 0 1 --- 3.2-17
SY.41 control word (high) 0029h rw np E 0 65535 0 1 hex 3.2-17, 3.2-18
SY.42 status word (high) 002Ah ro np --- 0 65535 0 1 hex 3.2-17, 3.2-18, 3.2-19
SY.43 control word (long) 002Bh rw np E -2^31 2^31 - 1 0 1 hex 3.2-17, 3.2-18, 3.7-6
SY.44 status word (long) 002Ch ro np --- -2^31 2^31 - 1 0 1 hex 3.2-17, 3.2-18, 3.2-19
SY.50 control word (low) 0032h rw np E 0 65535 0 1 hex
3.2-17, 3.2-18, 3.2-19, 3.7-
6,
Sy. 51 status word (low) 0033h ro np --- 0 65535 0 1 hex 3.2-17, 3.2-18, 3.2-19
Sy.56 Start display address 0038h rw np E 0 7FFFH 0200H 1 hex 3.2-20
ud.01 Password input 0801h cp-ro np o.P. 0 9999
APPLICA-
TION
1 --- 3.7-3, 4.2-34
ud.15 CP selector 080Fh rw np E 1 36 1 1 --- 3.9-3, 3.9-4, 3.9-6
ud.16 cp address 0810h rw np E -1:off 7FFFH CP-def. 1 hex 3.9-3, 3.9-4, 3.9-6
ud.17 cp set norm 0811h rw np E 1 8191 1 1 --- 3.9-3, 3.9-4, 3.9-6
ud.18 divisor display norm 0812h rw p E -32767 32767 1 1 --- 3.9-5, 3.9-7, 3.9-9
ud.19 multiplier display norm 0813h rw p E -32767 32767 1 1 --- 3.9-7, 3.9-9
ud.20 offset display norm 0814h rw p E -32767 32767 0 1 --- 3.9-7, 3.9-9
ud.21 ctrl. display norm 0815h rw p E 0 1791 0 1 --- 3.9-7, 3.9-8
