Page3.2 - 6 COMBIVERT R6-N © KEB, 2015-07

Operating and appliance data

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.13 Act. DC utilization 020Dh ro - - 0 255 1 % -

Display of the actual utilization referring to the rated current of the regenerative unit, depending on the oper-

ating mode (power supply or regenerative operation). Only positive values are displayed, whereby a differen-

tiation between supply and regeneration is not possible.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.14

Actual DC utilisation /

peak value

020Eh rw - - 0 255 1 % -

ru.14 permits the detection of short-time peak loads within an operating cycle. For that the highest value of

ru.13 is stored in ru.14. The peak value memory can be cleared by pressing the UP, DOWN or ENTER key

or via bus by writing any value you like to the address of ru.14. Switching off COMBIVERT also clears the

memory.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.15 DC current 020Fh ro - - 0,0 6553,5 0,1 A -

Display of the actual DC output current in ampere.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.16

DC output current / peak

value

0210h rw - - 0,0 6553,5 0,1 A -

ru.16 permits the detection of short-time peak loads within an operating cycle. For that the highest value of

ru.15 is stored in ru.16. The peak value memory can be cleared by pressing the UP, DOWN or ENTER key

or via bus by writing any value you like to the address of ru.16. Switching off COMBIVERT also clears the

memory.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.17 AC current 0211h ro - - -3276,7 3276,7 0,1 A -

Display of the actual input current.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.18 ref. DC voltage 212h ro - - 0 1000 1 V -

The DC voltage is measured at switching on and stored as reference value. The regenerative level (cS.02)

refers proportionally to this reference value and follows to the mains voltage.

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.19 DC output voltage 0213h ro - - 0 1000 1 V -

Display of the actual DC output voltage. The value is measured at the DC output terminals of the

COMBIVERT R6.
