KEB COMBIVERT R6-N

Operating and appliance data
© KEB, 2015-07 COMBIVERT R6-N Page3.2 - 7
3
10
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.20
DC output voltage / peak
value
0214h rw - - 0 778 1 V -
Parameter ru.20 enables to recognize voltage peaks within an operating cycle. For that the highest value of
ru.19 is stored in ru.20. The peak value memory can be cleared by pressing the UP, or DOWN key or via bus
by writing any value you like to the address of ru.20. Switching off COMBIVERT R6 also clears the memory.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.21 Input terminal state 0215h ro - - 0 4095 1 - -
Display of the digital inputs controlled currently. The logic levels are indicated at the input terminals or at the
internal inputs regardless of the following logic operations (see chapter 7.3 „Digital inputs“). According to
followingtableaspecicdecimalvalueisgivenoutforeachdigitalinput.Ifseveralinputsarecontrolled,the
sum of the decimal values is indicated.
Bit Decimal
value
Input Terminal
0 1 ST (prog. input „control release/reset“) X2A.12
1 2 RST (prog. input „reset“) no
2 4 F (prog. input) no
3 8 R (prog. input) no
4 16 I1 (prog. input 1) X2A.13
5 32 I2 prog. input 2) X2A.14
6 64 I3 (prog. input 3) X2A.15
7 128 I4 (prog. input 4) X2A.16
8 256 IA (internal input A) no
9 512 IB (internal input B) no
10 1024 IC (internal input C) no
11 2048 ID (internal input D) no
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
ru.22 Internal input state 0216h ro - - 0 4095 1 - -
Display of the digital external and internal inputs set currently. The input is only regarded as set if it is available
as effective signal to the further processing (i.e. accepted through strobe, edge-triggering or logic operation).
According to table like ru.21aspecicdecimalvalueisoutputforeachdigitalinput.Ifseveralinputsarecon-
trolled, the sum of the decimal values (see ru.21) is indicated (also see chapt. 3.4 „Digital inputs“).
