Page3.2 - 20 COMBIVERT R6-N © KEB, 2015-07
Operating and appliance data
10 reserved
11 reserved
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
Sy.56 Start display address 0038h rw - + 0 32767 1 - 512
Sy.56 adjusts the parameter address which shall be represented on switching on the operator. Operator
parameters can also be adjusted as starting display. Only valid addresses are accepted. If there is adjusted
an invalid address (neither in the inverter nor assigned in the operator) the operator searches for the next
existing address of the parameter group.
If this parameters is available in the CP mode, the setting becomes effective there. Otherwise CP.00 is indi-
cated as start parameter.
