KEB COMBIVERT R6-N User Manual

Operating and appliance data
© KEB, 2015-07 COMBIVERT R6-N Page3.2 - 19
3
10
SY.50: Control word low
Bit Function Value Description
3 reserved
0:reserved
8:reserved
4...6 Parameter set
0:Set0
Selection of the active parameter set, if in Fr.02 „parameter set
source“thevalue„5:controlword(SY.50)“ is programmed.
16:Set1
32:Set2
48:Set3
64:Set4
80:Set5
96:Set6
112:Set7
7 reserved
8 reserved
9 reserved
10 reserved
11 reserved
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
Sy. 51 Status word low 0033h ro - - 0 65535 1 - 0
The current condition of the COMBIVERT can be readout with the status word. The status word long (SY.44)
consists of the two 16 bit parameters status word high (SY.42) and status word low (SY.51). The status word
is bit-coded.
Bit Value Description
0 1:ST 1=set control release (AND operation with di.1 bit 0)
1 2:Error Inverter is in error state
2
0:Stop The modulation is switched off at „stop“ and switched on at „start“.
Exception:ifapositioningisstoppedwithbit11"stop"inthecon-
trol word, "stop" is displayed in the status word, if the drive reach-
es speed 0 (even if modulation is still active). This exception can
be reversed with bit 9 in parameter Pn.65 „special functions“.
4:Start
3 8:reserved
4...6
0:Set0
Display of the actual parameter set
16:Set1
32:Set2
48:Set3
64:Set4
80:Set5
96:Set6
112:Set7
7 reserved
8 reserved
9 reserved
continued on the next page
