CP 503/A, CP 505/A,D,K, CP 507/
A,C
Maintenance
Project engineering manual V1.06
70
© KEBA 2021
Removing the fan cover
To remove the fan cover, proceed as follows:
1) Disconnect the voltage supply.
2) Loosen the screws with the screwdriver.
3) Remove the fan cover
4) Disconnect the connection cable. To do this, carefully pull the plug up-
wards with the cable.
The fan has now been removed.
Inserting the fan cover
To insert the fan cover, proceed as follows:
1) Plug in the connection cable.
