38
T h e s e t u p o f v a l v e i n t e r v a l
Launch it under the cold state
1、Take down a rubber cover on the worm wheel body
2、Let the mark “T” on the flywheel be in the same level with the mark on the right cover.
3、Make sure that the timing carved line of cam chain snap to the critical surface of the cylinder head.
4、Check the interval of the intake valve and outtake valve, intake valve :0.03－0.05mm, outtake valve :0.05－0.06mm,
if it isn’t in the range of regulation value ,adjust the rocker arm and the screw to make the interval reach the stated
value range.
Valve interval
