48
S p e c i f i e d t o r q u e v a l u e
NO. Subject Total Value of fixed torque
Front wheel/Front shock absorber
1 Redirector and front wheel nut 2 70~83N.m
2 Front wheel and bolt of front hub 8 37~44N.m
3 Front shock absorber, frame and bolt of rocker 4 37~44N.m
Redirector
1 Up and down rockers and frame 8 37~44N.m
2 Redirector and up and down rockers 4 37~44N.m
Handle
1 Fixed nut of the ttubing lever lower part 1 37~44N.m
2 Clip seat and fixed nut of frame 2 22~29N.m
Rear wheel/Rear shock absorber
1 Rear axle and fixing seat of rear wheel 2 70~83N.m
2 Fixed nut of rear shock absorber upper part 1 37~44N.m
3 Fixed nut of rear shock absorber lower part 1 55~62N.m
4 Rear wheel and its fixing seat 8 37~44N.m
