Keithley 2000 Quick Reference Guide

45
Models 196/199 and 8840A/8842A commands
Table 16. Models 196/199 device-dependent command
summary
Mode Command Description
Execute X Execute other device-depen-
dent commands.
Function F0
F1
F2
F3
F4
F5
F6
F7
F8
F9
DC volts
AC volts
2-wire ohms
DC current
AC current
ACV dB
Not valid
Frequency
Temperature
4-wire ohms
Range
R0
R1
R2
R3
R4
R5
R6
R7
DCV
ACV DCA ACA Ohms* ACV dB Freq
Auto Auto Auto Auto Auto Auto —
1V 1V 100mA 1A 1kΩ 1V 0.1V
10V 10V 3A 3A 10kΩ 10V 1V
100V 100V 3A 3A 100kΩ 100V 10V
1000V 750V 3A 3A 1MΩ 750V 100V
1000V 750V 3A 3A 10MΩ 750V 750V
1000V 750V 3A 3A 100MΩ 750V —
1000V 750V 3A 3A 100MΩ 750V —
*2-wire and 4-wire ohms
Zero (rel) Z0
Z1
Z2
Zero disabled
Zero enabled
Zero enabled using a zero
value (V)
Filter P0
P1
P2
Filter disabled
Moving filter (count = 10)
Repeat filter (count = 10)
Rate S0
S1
S2
0.1 PLC integration
Line cycle integration
(16.67msec, 60Hz; 20msec,
50Hz)
10 PLC (166.67msec integra-
tion, 60Hz;
200msec integration, 50Hz)
2000-903-01A Page 45 Thursday, December 23, 1999 7:52 AM

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
