Keithley 2002

Performance Verification
1-7
Figure 1-2
Connections for AC volts verification (all except 2MHz)
2001 MULTIMETER
5700A Calibrator (Output AC Voltage)
5725 Amplifier (Connect to calibrator)
Input HI
Output HI
Input
LO
Output
LO
CA-18-1 Low-
capacitance cable
Model 2002
1.90000 VAC RMS
Figure 1-3
Connections for 2MHz AC volts verification
2002 MULTIMETER
BNC to dual
banana
50Ω
terminator
Model 2002
5700A Calibrator (Output AC Voltage)
5725 Amplifier (Connect to calibrator)
50Ω Coax
Wideband
output
1.90000 VAC RMS
