Specifications A-13
Maximum Input Levels
Overload
Rated Recovery
Input
1
Time
HI to LO ±1100V < 900 ms
HI Sense to LO ± 350V pk 250V rms < 900 ms
LO Sense to LO ± 150V pk 100V rms < 900 ms
I Input to LO 2A, ± 250V (fused) —
HI to Earth ±1600V < 900 ms
LO to Earth ± 500V
Note 1: For voltages between other terminals, these ratings
can be added.
Delay and Timer
Time Stamp Resolution: 1µs.
Accuracy: ±0.01% of elapsed time ± 1µs.
Maximum: 2,100,000.000000 seconds (24 days, 7 hours).
Delay Time (Trigger edge to reading initiation)
Maximum: 999,999.999 seconds (11 days, 14 hours).
Resolution: 1ms.
Jitter: ±1ms.
Timer (Reading initiation to reading initiation)
Maximum: 999,999.999 seconds (11 days, 14 hours).
Resolution: 1ms.
Jitter: ±1ms.
IEEE-488 Bus Implementation
Implementation IEEE-488.2, SCPI-1991.0.
Multiline Commands DCL, LLO, SDC, GET, GTL,
UNT, UNL, SPE, SPD.
Uniline Commands IFC, REN, EOI, SRQ, ATN.
Interface Commands SH1, AH1, T5, TE0, L4, LE0,
SR1, RL1, PP0, DC1, DT1, C0,
E1.
Digital I/O
Connector Type 8 pin “D” subminiature.
Input One pin, TTL compatible.
Outputs Four pins. Open collector,
30V maximum pull-up
voltage, 100mA maximum
sink current, 10Ω output
impedance.
Control Direct control by output or
set real-time with limits.
General Specifications and Standards Compliance
Power Voltage: 90–134V and 180–250V, universal self-selecting.
Frequency: 50Hz, 60Hz, or 400Hz, self-identifying at power-
up.
Consumption: <55VA.
Environmental Operating Temperature: 0°C to 50°C.
Storage Temperature: –40°C to 70°C.
Humidity: 80% R.H., 0°C to 35°C, per MIL-T-28800E
1
Para
4.5.5.1.2.
Calibration Type: Software. No manual adjustments required.
Sources: 2 DC voltages, 6 resistances, and 5 DC currents. All
other functions calibrated (adjusted) from these sources and
a short circuit. No AC calibrator required for adjustment.
Average Time to Perform: 40 minutes for comprehensive
calibration, 6 minutes for AC-only calibration.
Process MIL-STD 45662A.
Physical Case Dimensions: 90mm high × 214mm wide × 369mm deep
(3½ in. × 8½ in. × 14½ in.).
Working Dimensions: From front of case to rear including
power cord and IEEE-488 connector: 15.0 inches.
Net Weight: <4.2kg (<9.2 lbs.).
Shipping Weight: <9.1kg (<20 lbs.).
Standards EMI/RFI: Conforms to VDE 0871B (per Vfg 1046/1984), IEC
801-2. Meets FCC part 15 Class B, CISPR-22 (EN55022).
Safety: Conforms to IEC348, CAN/CSA-C22.2. No. 231, MIL-
T-28800E
1
. Designed to UL1244.
Accessories Supplied The unit is shipped with line cord, high performance modular
test leads, operator’s manual, option slot cover, and full
calibration data.
Note 1 For MIL-T-28800E, applies to Type III, Class 5, Style E.
Extended Memory/Non-Volatile Memory Options
DATA STORAGE
6½-Digit
Size with Setup Storage
Model (Bytes) 4½-Digit Time Stamp Type Number Type
2002 8k 2,027 404 volatile 1 non-volatile
2002/MEM1 32k 6,909 1,381 non-volatile 5 non-volatile
2002/MEM2 128k 29,908 5,980 non-volatile 10 non-volatile
These are the minimum sizes to expect.
Specifications subject to change without notice.
