Keithley 2002 Calibration Manual

Calibration Programs
B-2
Table B-1
Recommended equipment for comprehensive calibration
Mfg. Model Description Specifications*
Fluke 5700A Calibrator ±5ppm basic uncer-
tainty.
DC Voltage:
2V: ±7ppm
20V: ±5ppm
Resistance:
19Ω: ±26ppm
190Ω: ±17ppm
1.9kΩ: ±11ppm
19kΩ: ±11ppm
100kΩ: ±13ppm
1MΩ: ±18ppm
DC Current:
200µA: ±100ppm
2mA: ±55ppm
20mA: ±55ppm
200mA: ±65ppm
1A: ±110ppm
Keithley 8610 Low-thermal
shorting plug
* 90-day calibrator specifications shown include total uncertainty at speci-
fied output.
Table B-2
Recommended equipment for low-level calibration
Mfg. Model Description Specifications*
Fluke 5700A Calibrator ±5ppm basic uncertainty.
DC Voltage:
±2V: ±7ppm
+20V: ±5ppm
+100V: ±7ppm
Resistance:
19Ω: ±26ppm
190Ω: ±17ppm
1.9kΩ: ±11ppm
19kΩ: ±11ppm
100kΩ: ±13ppm
1MΩ: ±18ppm
DC Current:
200µA: ±100ppm
2mA: ±55ppm
20mA: ±55ppm
200mA: ±65ppm
1A: ±110ppm
AC Voltage:
0.5mV @ 1kHz:
±10000ppm
5mV @ 100kHz:
±2400ppm
200mV @ 1kHz:
±150ppm
1.5V @ 1kHz: ±80ppm
20V @ 1kHz: ±80ppm
20V @ 30kHz: ±140ppm
200V @ 1kHz: ±85ppm
200V @ 30kHz: ±240ppm
AC Current:
20mA @ 1kHz: ±160ppm
Keithley 3930A
or 3940
Synthesizer 2V rms @ 1Hz
Keithley 8610 Low-thermal
shorting plug
* 90-day calibrator specifications shown include total uncertainty at specified
output.

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
