Keithley 2110 Calibration Manual

Section
2: Adjustment Model 2110 5½ Digit Multimeter
Calibration Manual
2-8 2110-905-01 Rev. C / August 2013
36. Set the Model 5700A output to 100kΩ.
37. Adjust full scale measurement by sending the following command:
CAL:PROT:DC:STEP 2,<ACTUAL CALIBRATOR OUTPUT>
38. Wait until the following message is displayed on the Model 2110:
Cali OK
39. Set the Model 5700A output mode to STANDBY.
40. Configure the Model 2110 for 2-wire, 1MΩ resistance measurements by sending the following
command:
CONF:RES 1E6
41. Set the measurement rate to 10 PLC by sending the following command:
RES:NPLC 10
42. Set the Model 5700A to 0Ω and the output mode to OPERATE.
43. Adjust input offset by sending the following command:
CAL:PROT:DC:STEP 1,0
44. Wait until the following message is displayed on the Model 2110:
Cali OK
45. Set the Model 5700A output to 1 MΩ.
46. Adjust full scale measurement by sending the following command:
CAL:PROT:DC:STEP 2,<ACTUAL CALIBRATOR OUTPUT>
47. Wait until the following message is displayed on the Model 2110:
Cali OK
48. Set the Model 5700A output mode to STANDBY.
49. Configure the Model 2110 for 2-wire, 10 MΩ resistance measurements by sending the following
command:
CONF:RES 1E7
50. Set the measurement rate to 10 PLC by sending the following command:
RES:NPLC 10
51. Set the Model 5700A to 0Ω and the output mode to OPERATE.
52. Adjust input offset by sending the following command:
CAL:PROT:DC:STEP 1,0
53. Wait until the following message is displayed on the Model 2110:
Cali OK
54. Set the Model 5700A output to 10MΩ.
55. Adjust full scale measurement by sending the following command:
CAL:PROT:DC:STEP 2,<ACTUAL CALIBRATOR OUTPUT>
56. Wait until the following message is displayed on the Model 2110:
Cali OK
57. Set the Model 5700A output mode to STANDBY.

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
