Section 9: Introduction to TSP operation Series 3700A System Switch/Multimeter Reference Manual
9-22 3700AS-901-01 Rev. D/June 2018
Bit operations
The rest of the functions in this group are used for operations on the bits of a given number. These
functions can be used to:
▪ Clear a bit
▪ Toggle a bit
▪ Test a bit
▪ Set a bit or bit field
▪ Retrieve the weighted value of a bit or field value
All these functions use an index parameter to specify the bit position of the given number. The least
significant bit of a given number has an index of 1, and the most significant bit has an index of 32.
The Test Script Processor (TSP) scripting engine stores all numbers internally as IEEE Std 754
double-precision floating-point values. The logical operations work on 32-bit integers. Any fractional
bits are truncated. For numbers larger than 4294967295, only the lower 32 bits are used.
bit.bitand() (on page 11-9)
bit.bitor() (on page 11-9)
bit.bitxor() (on page 11-10)
bit.clear() (on page 11-11)
bit.get() (on page 11-11)
bit.getfield() (on page 11-12)
bit.set() (on page 11-13)
bit.setfield() (on page 11-14)
bit.test() (on page 11-15)
bit.toggle() (on page 11-15)

Keithley 3721-ST Specifications

General

Type	Multimeter
Model	3721-ST
Manufacturer	Keithley
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
Relay Type	Electromechanical
Temperature Range	-200°C to 1820°C
Accuracy	Varies by function and range
Resolution	Varies by function and range
Display	LCD
Interface	GPIB, RS-232
Topology	Multiplexer
Maximum Switching Voltage	300 V
Maximum Switching Current	1 A
Input Impedance	>10 GΩ (DC Voltage ranges)
