Keithley 3721-ST User Manual

Series 3700A System Switch/Multimeter Reference Manual Section 11: TSP command reference
3700AS-901-01 Rev. D/June 2018 11-165
dmm.configure.recall()
This function recalls a user or factory DMM configuration and replaces attributes in the present configuration with
attributes from the recalled version.
Type
TSP-Link accessible
Affected by
Where saved
Default value
Function
Yes
Usage
dmm.configure.recall("configuration")
configuration
A string that represents the name of the DMM configuration to recall
Details
This command recalls the DMM configuration for one function.
When a configuration is recalled, the function associated with the configuration becomes active.
When you recall a DMM configuration, the existing DMM configuration settings for the function are
replaced by the settings in the recalled configuration. Settings for other functions are not affected. For
example, if the function associated with the configuration was temperature, only temperature settings
are recalled. If a factory configuration is recalled, the function's attributes are set to their factory
default values.
The DMM configuration can be user-defined or factory-defined.
User-defined DMM configurations are set with dmm.configure.set(). The factory-defined DMM
configurations are:
▪ "accurrent"
▪ "acvolts"
▪ "commonsideohms"
▪ "continuity"
▪ "dccurrent"
▪ "dcvolts"
▪ "fourwireohms"
▪ "frequency"
▪ "nofunction"
▪ "period"
▪ "temperature"
▪ "twowireohms"

Keithley 3721-ST Specifications

General

Type	Multimeter
Model	3721-ST
Manufacturer	Keithley
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
Relay Type	Electromechanical
Temperature Range	-200°C to 1820°C
Accuracy	Varies by function and range
Resolution	Varies by function and range
Display	LCD
Interface	GPIB, RS-232
Topology	Multiplexer
Maximum Switching Voltage	300 V
Maximum Switching Current	1 A
Input Impedance	>10 GΩ (DC Voltage ranges)
