Pin Signal
X7
Main transformer connections
X8 Main transformer connections
X17 Main transformer connections
X19 Main transformer connections
Pin Signal
X9 PFC auxiliary voltage connector
Pin
Signal
Description
X10:1 Inrush Relay Other end of the inrush relay coil
X10:2 OV Opto P Over voltage optocoupler other end
X10:3 Primary current transformer Primary current transformer other end
X10
:4
Inrush Relay
Other end of the
inrush relay coil
X10:5 OV Opto N Over voltage optocoupler other end
X10:6 Primary current transformer Primary current transformer other end
X10:7 IGBT Drive B Other end of the IGBT driver transformer primary
X10
:
8
PFC ON/OFF P
PFC on/off opto coupler
diode positive end
X10
:
9
-
-
X10:10 IGBT Drive A Other end of the IGBT driver transformer primary
X10:11 PFC ON/OFF N PFC on/off opto coupler diode negative end
X10
:
12
-
-
Pin Signal
X
11
PFC choke connections
X
12
PFC choke connections
X14
PFC
choke connections
X15 PFC choke connections
Pin Signal
X13
DC
-
link voltage
X16
DC
-
link voltage
