4. OPERATION AND USE OF POWER SOURCE
4.1. KEMPOMAT PANELS
Wire feed panel
Push-pull gun connector and
switch (accessory)
Welding gun connector (EURO)
Mounting place for MSD 1 V/A
metering unit (accessory)
Signal lamp for Kempomat
4000 main switch
Signal lamp for overheating
(power source)
Kempomat 3200 main switch
Kempomat 4000 main switch and
voltage selecting range
Voltage selecting switch
(ne grading)
Voltage selecting switch (coarse grading)
I Return current dix-connector
(coarser arc)
II Return current dix-connector
(softer arc)
Control fuse (8 A delayed)
Shielding gas connector
Inlet of mains cable
Fan and inlet opening
