Kemppi Kempomat 2500 Operation Instructions

 COPYRIGHT KEMPPI OY
2 / Kempomat 2500, Kempomat 3200, Kempomat 4000 / 0340
Kempomat 2500, Kempomat 3200, Kempomat 4000 / 0340 / 3
 COPYRIGHT KEMPPI OY
1. PREFACE
1.1. INTRODUCTION
Congratulations on having purchased a KEMPPI product. Properly installed and used Kemppi
products should prove to be productive machines requiring a small mount of seasonal mainte-
nance. This manual is arranged to give you a good understanding of the equipment and its
safe operation. It also contains maintenance information and technical specications. Read this
manual completely from front to back before installing, operating or maintaining the equipment
for the rst time. For further information on Kemppi products please contact us or your nearest
Kemppi distributor.
The specications and designs presented in this manual are subject to change without prior
notice.
In this document, where ever there exists a danger to life or injury the following symbol is
used:
Read the warnings carefully and follow the instructions. Please also study the Operation safety
instructions and respect them when installing, operating and servicing the machine.
1.2. PRODUCT INTRODUCTION
The power sources Kempomat 3200 and 4000 are compact MIG welding machines, designed
for heavy industrial use. Kempomat 2500 is compact MIG welding machine, designed for repair
shops and light and heavy industrial use.
Power source
Supply voltage of the Kempomat 3200 power source is 3~ 230 V / 400 V. Voltage of power
source is adjusted with turn type switches; together 16 steps. In Kempomat 4000 product range
there are different units for mains voltages 3~ 230 and 400 V and the welding voltage adjustment
is made in 32 steps. The Volt/Ampere metering unit MSD 1 (available as accessory) displays
voltage or welding current.
Wire feeder unit
The wire feeder unit is a 4-roll driven xed unit in the equipment, suitable for air-cooled guns.
Accessory unit KMW sync is needed for connection and use of push-pull guns Binzel and
Hulftegger. Accessory unit KMW timer controls continuous, spot and cycle-arc welding.
2. INSTALLATION OF THE POWER SOURCE
2.1. TRANSPORT AND LIFTING OF THE MACHINE
On the Kempomat power source bottom there are four xed lifting points for lifting devices,
hole diameter 47 mm.
On the power source´s front panel there are handles designed for moving the units on the oor.
Lift the entire machine only from lifting points in the bottom plate without gas
bottle
You may move the units from handles only by hands, it is forbidden to use any
mechanical devices!
Ensure that the unit is kept during lifting between lifting linens. When necessary use additional
binding round the lifting linens and the unit´s upper part. Use the protection between the lifting
device and the unit in order to eliminate impacts and shocks.
