KENT SP500 - Screen End and Angle Adjustment

01/28/02
Page 8.4
Setup
Kent Pad Printer Canada Inc.
To level one end of screen
Angle adjustment of screen
Loosen locking screws
Level by knobs
To level turn both
knobs in same direction
Loosen locking screw
Level by knob
On both screen holders
To level turn both
knobs in same direction
Loosen locking screw
Adjust by knob
On both screen holders
To adjust turn both
knobs in opposite
directions
