Basic Operations
10
Number Name Motion
3
CAM • Switches view camera display on/off.
The camera whose view is displayed first changes according to the "Camera Setup"
setting and the shift lever position in the shift gate. The camera whose view was
displayed last is kept and the same camera view will be displayed the next time. If its
assignment setting is changed, the rear camera view is displayed.
• Pressing and holding turns the screen off. (DDX9020DABS / DDX8020S only)
4
HOME • Displays the HOME screen (P.16).
• Pressing for 1 second turns the power off.
• When the power is off, turns the power on.
5
MENU • Displays the popup menu screen.
• Pressing for 1 second switches attenuation of the volume on/off. (DDX9020DABS /
DDX8020S only)
• Pressing for 1 second turns the screen off. (DMX8520DABS / DMX8020S only)
6
• Displays the APP (Apple CarPlay/Android Auto/Wireless Mirroring) screen.
• Pressing and holding displays the Voice Recognition screen (P.61).
• When neither Apple CarPlay, Android Auto, nor a Bluetooth Hands-Free phone is
connected, pressing and holding displays Bluetooth pairing waiting dialog. ( P.54)
7
G
• Displays the Angle Adjust screen.
– [DISC EJECT]: Ejects the disc.
• When the panel is opened, closes the panel.
• To forcibly eject the disc, press it for 2 seconds and then touch [DISC EJECT] after the
message is displayed.
8
AT T • Switches attenuation of the volume on/off.
9
Disc insert
slot
• A slot to insert a disc media.
(DDX9020DABS / DDX8020S only)
Turning on the Unit
The method of turning on is different
depending on the model.
DDX920WDABS / DDX820WS /
DMX820WS
1
Touch the display.
The unit is turned on.
DDX9020DABS / DMX8520DABS /
DDX8020S / DMX8020S
1
Press the [HOME] button.
DDX9020DABS / DDX8020S
DMX8520DABS / DMX8020S
The unit is turned on.
● To turn off the unit:
1
Press the [HOME] button for 1 second.
NOTE
• If it is your first time to turn the unit on after
installation, it will be necessary to perform Initial
SETUP (P.11).
To Next Page
