6.3 Assemble windshield (only models d = 0.001g)
Parts overview:
Quantit
y
Quanti
ty
Guide frame
1
Front plate (with 3 bore holes)
1
Rear wall
1
Inner plate
1
Handle
3
Side wall
3
Fastening screw “Handle”
5
Base frame
1
Cover
2
Front cap
2
Support inner plate
2
M4 screws
4
