5. Malfunctions
Power – LED is on
Alarm-LED blinks
Flap – LED blinks
Audible alarm
Power – LED is on
Alarm –LED blinks
Backwater – LED
blinks
Backwater flap –
LED blinks
Audible alarm
sounds
- The motorized backwater
flap cannot fully close most
likely due to an obstruction
in its path.
- Levers on Ecolift cover
were not in correct position
when the cover was instal-
led
- Backwater has been detec-
ted but the motorized back-
water flap cannot close fully
(most likely a blockage).
Unplug control unit and disconnect
batteries. Remove Ecolift cover and
remove any obstruction. Reconnect
batteries and plug in control unit
Recommendation: inform your aut-
horized KESSEL customer service
partner
See User’s
Manual 010-844 (Sections 4.2.1)
- Close the emergency manual flap
lever. After the backwater occur-
rence is over attempt to remove
the blockage as described in this
manual.
Attention: check backwater flap
operation lever! In the case that
the motorized backwater flap can-
not fully close, the Ecolift will per-
form 3 flap closure attempts in an
effort to dislodge any obstruction
that may be preventing the flap
from fully closing. If any of these 3
attempts are successful, then the
Ecolift will return to normal operati-
on and no alarm warnings will
sound. If these 3 attempts are not
successful then an alarm will
sound – this alarm can be acknow-
ledged by pressing the correct but-
ton on the control unit. Allowing
wastewater to drain through the
Ecolift may also help dislodge any
obstruction. Pressing the flap clo-
sure button can test to see if the
flap can now fully close. In the case
that the obstruction has not been
cleared then the alarm will activate
again and the object will need to be
removed as discussed below.
The KESSEL control unit can self-diagnose problems that can arise during commissioning as well as operation of the Ecolift and aid
in correcting any problems.
5.1 Malfunctions during power operation – LED display Page 8
Error display Cause Corrective action Advice
Power – LED blinks
Alarm – LED blinks
Audible alarm
Power – LED is on
Alarm- LED blinks
fast
Flap – LED blinks
Audible alarm
Power – LED is on
Alarm- LED blinks
fast
Backwater – LED
blinks
Audible alarm
Battery is not connected or
defective
Commissioning : Motor cable
not properly connected or
damaged
Operation: Motor cable de-
fective or motor is defective
Commissioning: Optical
sensor cable not properly
connected or damaged
Operation: Optical sensor
cable defective or sensor is
damaged
Unplug control unit, disconnect bat-
teries and replace with new batte-
ries if required. If the control unit is
now operational, the control unit’s
LEDs will display this.
Unplug control unit and disconnect
batteries. Check to make sure
motor cable is properly connected,
replace motor if necessary.
Unplug control unit and disconnect
batteries. Check to make sure opti-
cal sensor cable is properly connec-
ted, replace optical sensor if neces-
sary.
Commissioning: the Ecolift can be
placed into operation even if there is
a problem with the batteries – the
alarm notification can be acknowled-
ged
Operation: The battery fault alarm
will sound within 5 minutes. The sy-
stem is fully operational. Manual
operation is also possible.
This error will only be detected in ope-
rational mode (see Section 8.2 ‘Addi-
tional Functions’)
Commissioning: Commissioning is not
possible with this error
Operation: The error will be detected
during backwater or by manually ac-
tivating a test cycle on the control unit
The optical sensor cable is automa-
tically checked every 2 seconds
Power – LED is on
Alarm - LED and
Backwater flap – LED
blink alternatingly
Maximum flap closure limit
has been exceeded
Maximum motor operational
hours has been exceeded
Replace motor
Contact KESSEL Customer
Service Partner
Lifespan of motor has been ex-
ceeded
Backwater flap is closing too often
in short periods of time
Power – LED is on
Alarm - LED and
Backwater flap – LED
blink simultaneously
