Keymile SUPM1 - Page 77

User Manual
SUPM1
page 77 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
User Interface Reference
a-GND Not Used
Alarm threshold resistance between a-wire and
ground.
10 kOhm
20 kOhm
30 kOhm
40 kOhm
50 kOhm
100 kOhm
b-GND Not Used
Alarm threshold resistance between b-wire and
ground.
10 kOhm
20 kOhm
30 kOhm
40 kOhm
50 kOhm
100 kOhm
Line Test Alarm
Thresholds, For-
eign DC Voltage
a-b Not Used
Alarm threshold foreign DC voltage between a-
wire and b-wire.
10 V
20 V
30 V
40 V
50 V
60 V
a-GND Not Used
Alarm threshold foreign DC voltage between a-
wire and ground.
10 V
20 V
30 V
40 V
50 V
60 V
b-GND Not Used
Alarm threshold foreign DC voltage between b-
wire and ground.
10 V
20 V
30 V
40 V
50 V
60 V
Table 42: AP: / unit-x, Configuration - Line Test Alarm Thresholds (continued)
Operation Name Parameter Name Range Description / Details
