8.2.4 AP: / unit-x, Fault Management
For the a description of the general aspects of the
− “Fault Management - Status”, and
− “Fault Management - Configuration”
management functions, please refer to [302] User Guide “XMC25/XMC23/
XMC22”. The following table lists the fault causes of the current AP.
Line Test Alarm
Thresholds, For-
eign AC Voltage
a-b Not Used
Alarm threshold foreign AC voltage between a-
wire and b-wire.
5 Veff
10 Veff
20 Veff
30 Veff
40 Veff
a-GND Not Used
Alarm threshold foreign AC voltage between a-
wire and ground.
5 Veff
10 Veff
20 Veff
30 Veff
40 Veff
b-GND Not Used
Alarm threshold foreign AC voltage between b-
wire and ground.
5 Veff
10 Veff
20 Veff
30 Veff
40 Veff
Line Test Alarm
Thresholds, Noise
Noise Not Used
Alarm threshold noise level between a-wire and
b-wire.
40 -dBm
30 -dBm
20 -dBm
10 -dBm
Table 42: AP: / unit-x, Configuration - Line Test Alarm Thresholds (continued)
Operation Name Parameter Name Range Description / Details
Table 43: AP: / unit-x, Fault Management
ID Fault Cause Event Type Traffic
Affecting
Default
Severity
Description
SWM Software Mismatch Equipment
Alarm
Minor The running ESW does not match the
assigned ESW.
SSWNA Scheduled Software
Not Available
Equipment
Alarm
Minor The ESW that is scheduled for installa-
tion is not available on the unit. Make
sure that the ESW is downloaded to the
unit.
