SWIN Software Incompatible
With Network Element
Equipment
Alarm
Major The running ESW is not compatible with
the version required by the NE type or
version.
PRC PBUS Resource Con-
flict
Processing
Error Alarm
Major The PBUS access circuit of another TDM
unit in the subrack is defective.
Remove or unassign the other TDM units
in the subrack one by one until the alarm
is cleared. Replace the defective unit.
EQM Equipment Malfunction Equipment
Alarm
Critical The SUPM1 controller detects any
anomalies on the unit, e.g. a voltage is
missing, a chip does not respond, etc.
RSF Ring Supply Failure Equipment
Alarm
Critical Ring Supply Failure.
TEL Temperature Exceeds
Limit
Environmen-
tal Alarm
Warning The temperature measured on the
SUPM1 unit exceeds 70°C, SUPM1
reaches overheat state 1.
TEU Temperature Unaccept-
able
Environmen-
tal Alarm
Major The temperature measured on the
SUPM1 unit exceeds 85°C, SUPM1
reaches overheat state 2.
SHT Shutdown Time-Out Communica-
tion Alarm
Major 30 minutes after starting the shutdown
function on the unit layer, applied via the
EM, this alarm will remind you that at
least one user port is still unlocked.
HWIC Hardware Incompatible
With Configuration
Equipment
Alarm
Major The plugged HW is not compatible with
the unit configuration HW stored in the
database. You may need to change the
HW or re-create the configuration for the
unit.
SWIC Software Incompatible
With Configuration
Equipment
Alarm
Major The ESW running on the unit is not com-
patible with the unit configuration stored
in the database. You may need to
upgrade, or downgrade the ESW, or re-
create the configuration with the cur-
rently running ESW.
GSW General Software
Alarm
Equipment
Alarm
Major An ESW internal error has been detected
that might inhibit the ESW from running
correctly.
MFA Maintenance Function
Active
Communica-
tion Alarm
Warning A maintenance function has been acti-
vated by the operator from the unit sta-
tus.
UNAV Unit Not Available Equipment
Alarm
Critical The unit that is configured is either not
plugged or not recognized due to a fail-
ure.
NSW No Application Soft-
ware
Equipment
Alarm
Major There is no application ESW installed on
the unit, or the application ESW has not
yet finished its boot process.
UNAS Unit Not Assigned Equipment
Alarm
Warning The unit is not assigned and cannot be
configured. To assign the unit, execute
the “Assign” command in the “Main”
function of the unit.
UIC Unit Incompatible Equipment
Alarm
Major The inserted unit is not compatible with
the assigned unit.
Table 43: AP: / unit-x, Fault Management (continued)
ID Fault Cause Event Type Traffic
Affecting
Default
Severity
Description
