User Interface Reference
8.3.6.2 AP: / unit-x / port-y, Status - Line Test
Table 53: AP: / unit-x / port-y, Status - Line Test
Operation Name Parameter Name Range Description / Details
Start Line Test
Start a manual line-test on the user port.
Line Test Status Time Stamp DD.MM.YYYY hh:mm:ss
Date and time of the last performed line-test.
State Aborted
Please refer to the line-test functional
description in section 5.11 Line Test (on
page 52)
Requested
Rejected
Running
Passed
Failed
Not Tested
See Results
Results
The line-test results comprise the Test
Description, the Status and the Measured
Value.
Please refer to the line-test functional
description in section 5.11 Line Test (on
page 52)
Results - Test
Description
Foreign DC Voltage a-GND
Line-test description.
Foreign DC Voltage b-GND
Foreign DC Voltage a-b
Foreign AC Voltage a-GND
Foreign AC Voltage b-GND
