User Interface Reference
Table 52: AP: / unit-x / port-y, Status - Maintenance
Operation Name Parameter Name Range Description / Details
User Port Status
a
Usage State Busy
Note: In the MCAS mode of operation, the usage
state is only valid when the IETF operational
state is up.
Idle
Admin State Locked
X.731 administrative status.
In the non-V5CAS operation modes the Admin
State is “Unlocked”.
Shutting Down
Unlocked
Oper State Disabled
X.731 operational status.
In the non-V5CAS operation modes the Oper
State is derived from the CAS AIS state:
- “Enabled” without AIS
- “Disabled” with AIS
Enabled
Undefined
Shutdown
b
Shutdown the user port. The port is blocked as
soon as the usage state “idle” has been
detected.
Administrative state = locked.
Lock
b
Lock the user port. The port is blocked immedi-
ately.
Administrative state = locked.
Unlock
b
Unlock the user port. The port is unblocked with
this command.
Administrative state = unlocked.
a. The actual user port status is controlled by the local exchange, the subscriber or the management system. Please refer
to section 5.5 Port States (on page 43).
b. This command is only available for the V5CAS mode of operation.
