User Interface Reference
8.3.6.3 AP: / unit-x / port-y, Status - Test Loop
Foreign AC Voltage a-b
Isolation a-GND
Isolation b-GND
Resistance b-a
Resistance a-b
Capacitance a-GND
Capacitance b-GND
Capacitance a-b
Noise
Results – Status OK
Line-test status.
Failed
Not Tested
Untestable
Cleared
Results - Measured
Value
0 … 30 characters
Line-test measured value.
Table 53: AP: / unit-x / port-y, Status - Line Test (continued)
Operation Name Parameter Name Range Description / Details
Table 54: AP: / unit-x / port-y, Status - Test Loop
Operation Name Parameter Name Range Description / Details
Test Loop Test Loop Enabled
Activation state of the test loop.
Please refer to the test loop functional
description in section 5.6.3 Test Loop Proce-
dure (on page 45).
Enable test loop
Activate the loopback of the digital voice sig-
nal towards the network.
Disable test loop
Deactivate the loopback of the digital voice
signal towards the network.
