Keysight Models 6811C, 6812C, and 6813C Quick Start Guide 25
Use ▲ or ▼ to
navigate between
the Output
function
commands.
IMP:REAL <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set real part of output impedance.
IMP:REAC <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set reactive part of output
impedance.
PON:STATE RST | RCL0
Use ▲ or ▼ to navigate between
RST | RCL0. Press [Enter] to save.
Select power-on state command.
RI LATCHING | OFF | LIVE
Use ▲ or ▼ to navigate between
LATCHING | OFF | LIVE. Press
[Enter] to save.
Set remote inhibit mode.
DFI ON | OFF
Use ▲ or ▼ to navigate between
ON | OFF. Press [Enter] to save.
Set discrete fault indicator state.
DFI:SOUR QUES | OPER | ESB |
RQS | OFF
Use ▲ or ▼ to navigate between
QUES | OPER | ESB | RQS | OFF.
Press [Enter] to save.
Select the DFI source.
Use ▲ or ▼ to
navigate between
the Freq function
commands.
FREQ <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set immediate output frequency.
FREQ:T <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set triggered output frequency.
FREQ:M FIXED | LIST | PULSE |
STEP
Use ▲ or ▼ to navigate between
FIXED | LIST | PULSE | STEP. Press
[Enter] to save.
Select the frequency mode.
SLEW <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set frequency slew in Hz/sec.
Function
key press
Function command on
the front panel display
Entry key press Description
