26 Keysight Models 6811C, 6812C, and 6813C Quick Start Guide
Use ▲ or ▼ to
navigate between
the Freq function
commands.
SLEW:T <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set triggered frequency slew Hz/
sec.
SLEW:M FIXED | LIST | PULSE |
STEP
Use ▲ or ▼ to navigate between
FIXED | LIST | PULSE | STEP. Press
[Enter] to save.
Select the frequency slew mode.
Use ▲ or ▼ to
navigate between
the Phase function
commands.
PHASE <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set immediate output phase.
PHASE:T <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set triggered output phase.
PHASE:M FIXED | LIST | PULSE |
STEP
Use ▲ or ▼ to navigate between
FIXED | LIST | PULSE | STEP. Press
[Enter] to save.
Select the phase mode.
Use ▲ or ▼ to
navigate between
the Protect
function
commands.
PROT:CLEAR Press [Enter] to execute. Clear latched protection signal.
CURR:PROT ON | OFF
Use ▲ or ▼ to navigate between
ON | OFF. Press [Enter]
to save.
Set overcurrent protection
function.
VOLT:PROT ON | OFF
Use ▲ or ▼ to navigate between
ON | OFF. Press [Enter] to save.
Set overvoltage protection
function.
VOLT:PROT <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set overvoltage protection level.
DELAY <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set a time delay for activating a
protection fault.
Function
key press
Function command on
the front panel display
Entry key press Description
