Keysight Models 6811C, 6812C, and 6813C Quick Start Guide 27
Use ▲ or ▼ to
navigate between
the Status function
commands.
CLS
Press [Enter] to execute. Execute the *CLS command.
STATUS:PRESET Press [Enter] to execute.
Execute STATus:PRESet
command.
ESR? <value>
Press [Enter] to display the
information for command.
Return event status register value.
STB <value>
- Return status byte register value.
OPER:EVEN? <value>
Press [Enter] to display the
information for command.
Return STAT:OPER:EVENT? value.
OPER:COND <value> - Return STAT:OPER:COND? value.
QUES:EVEN? <value>
Press [Enter] to display the
information for command.
Return STAT:QUES:EVENT? value.
QUES:COND <value> - Return STAT:QUES:COND? value.
Use ▲ or ▼ to
navigate between
the Shape function
commands.
SHAPE SINE | SQUARE | CSIN |
<user>
Use ▲ or ▼ to navigate between
SINE | SQUARE | CSIN | <user>.
Press [Enter] to save.
Set immediate waveform shape.
SHAPE:T SINE | SQUARE | CSIN |
<user>
Use ▲ or ▼ to navigate between
SINE | SQUARE | CSIN | <user>.
Press [Enter] to save.
Set triggered waveform shape.
SHAPE:M FIXED | LIST | PULSE |
STEP
Use ▲ or ▼ to navigate between
FIXED | LIST | PULSE | STEP. Press
[Enter] to save.
Set waveform shape mode.
CLIP <value>
Use keypad to key in an exact
value, alternatively use ▲ to
increment or ▼ to decrement.
Press [Enter] to save.
Set clipping level.
Function
key press
Function command on
the front panel display
Entry key press Description
