7 Characteristic and Specifications
194 E364xA User’s and Service Guide
Supplemental Characteristics
Table 7-3 Supplemental characteristics
Parameters E3646A E3647A E3648A E3649A
Output programming range
(maximum programmable
values)
Low range 0 to +8.24 V 0 to +36.05 V 0 to +8.24 V 0 to +36.05 V
0 to 3.09 A 0 to 0.824 A 0 to 5.15 A 0 to 1.442 A
High range 0 to +20.6 V 0 to +61.8 V 0 to +20.6 V 0 to +61.8 V
0 to 1.545 A 0 to 0.515 A 0 to 2.575 A 0 to 0.824 A
OVP 1 V to 22 V 1 V to 66 V 1 V to 22 V 1 V to 66 V
Remote sensing
capability
Voltage drop Up to 1 V per each lead
Load regulation Add 5 mV to specification for each 1 V change in the + output lead due to
load current changes.
Load voltage Subtract the voltage drop in load leads from the specified output voltage
rating.
Temperature coefficient
[a]
±(% of output + offset)
Voltage <0.01% + 3 mV (<0.02% + 5 mV for output 2)
Current <0.02% + 3 mA
Stability
[b]
±(% of output + offset)
Voltage <0.02% + 2 mV
Current <0.1% + 1 mA
Output voltage overshoot
[c]
<1 V
Programming language SCPI (Standard Commands for Programmable Instruments)
State storage memory Five user-configurable stored states
Recommended calibration
interval
1 year
Output terminal isolation
(maximum, from chassis
ground)
– ±60 Vdc when connecting shorting conductors without insulation
between the (+) output and the (+) sense terminals and between the (–)
output and the (–) sense terminals.
– ±240 Vdc when connecting insulated shorting conductors between the (+)
output and the (+) sense terminals and between the (–) output and the (–)
sense terminals.
