Operation and Features 2
E364xA User’s and Service Guide 63
View Mode Operation
From the View menu, you can read the errors, firmware revision, and calibration
string. In addition, you can change the front panel display mode to V-V display, I-I
display, or V-I display as desired. With this V-V or I-I display mode setting, you
can see voltages or currents on the output1 and the output2, simultaneously.
– After the display mode is set to V-V or I-I, you cannot change the limit values.
If you attempt to change the limit values by turning the knob or pressing one of
the following keys — , , , , or , the front panel display will
automatically return to the normal display to allow you to change the limit
values.
– After the display mode is set to V-V or I-I, all the annunciators remain
unchanged.
– To exit the view menu without any changes, press until NO CHANGE is
displayed, or select EXIT by turning the knob and press .
Changing the display mode
1 Enter the view menu.
If ERRORS appears when you enter the view menu, one or more command
syntax or hardware errors have been detected. Then turn the knob until
“DISPLAY” is displayed.
2 Select the display mode you want to display.
Select one of the following display modes by turning the knob — V-V DISPLAY,
I-I DISPLAY, or V-I DISPLAY.
3 Save the change and exit the menu.
DISPLAY
V-I DISPLAY
