Operation and Features 2
E364xA User’s and Service Guide 61
Track Mode Operation
This power supply provides tracking outputs. In the track mode, two voltages of
the output1 and the output2 supplies track each other within the voltage
programming accuracy as described on “Supplemental Characteristics” on
page 194 for convenience in varying the symmetrical voltages needed by
operational amplifiers and other circuits using two balanced outputs. The track
mode is always in the off state when power has been turned off or after a remote
interface reset.
Front panel operation
1 Set either the output1 or the output2 supply to the desired voltage.
2 Enable the track mode.
Hold down until the Track annunciator turns on. For example, when the
track mode is first enabled with the output1 selected, the output2 supply will
be set to the same voltage level as the output1 supply. Once enabled, any
change of the voltage level in either the output1 or the output2 supply will be
reflected in other supply. The current limit is independently set for each of the
output1 or the output2 supply and is not affected by the track mode.
3 Exit the track mode.
The Track annunciator turns off.
HOLD_KEY
The tracking accuracy is dependent upon the voltage programming accuracy of
each output. Refer to “Electrical Specifications” on page 192 for more
information.
