2Operation and Features
78 E364xA User’s and Service Guide
Front panel operation
To reset the power supply to the power-on reset state without using the *RST
command or turning power off/on, select RESET from the following.
Remote interface operation
Use the following commands to store and recall power supply states.
To assign a name to a stored state to be recalled from the front panel, send the
following command. From the remote interface, you can only recall a stored state
using a number (1 through 5).
Self-test
A power- on self-test occurs automatically when you turn on the power supply.
This test assures you that the power supply is operational. This test does not
perform the extensive set of tests that are included as part of the complete self-
test described below. If the power- on self- test fails, the ERROR annunciator
turns on.
A complete self-test performs a series of tests and takes approximately 2 seconds
to execute. If all tests pass, you can have a high confidence that the power supply
is operational.
If the complete self-test is successful, PASS is displayed on the front panel. If the
self-test fails, FAIL is displayed and the ERROR annunciator turns on. Refer to
Chapter 8, "Service and Maintenance" for instructions on returning the power
supply to Keysight for service.
STORE STATE, NAME STATE, EXIT
5 states, RESET, EXIT
*SAV {1|2|3|4|5}
*RCL {1|2|3|4|5}
MEM:STAT:NAME 1, ‘P15V_TEST’
