8 Service and Maintenance
238 E364xA User’s and Service Guide
14 Enter the computed value (DVM reading divided by the shunt resistance) by
using the knob and resolution selection keys.
15 Save the change and select the high current calibration point.
16 Enter the computed value (DVM reading divided by the shunt resistance) by
using the knob and resolution selection keys.
17 Save the new current calibration constants for the output1 and go to the
calibration mode for the output2.
If the calibration fails, an error message will be displayed for one second and
you will hear a beep, and then return to the current calibration mode again.
18 Repeat step 3 through step 16 for the voltage, OVP and current calibration.
19 Exit the calibration mode.
The message above appears if the calibration is successful. If the calibration
fails, an error message will be displayed for one second and you will hear a
beep, and then return to the current calibration mode again.
I MI 1.540,0
I HI 2.800,0
I HI 2.789,0
VOLT2 CAL
CAL MODE
