6 Remote Operations
76 Keysight J7201A/B/C Operating and Service Manual
*SRE <Integer>
Examples
To set the bit in the status byte enable register to 128:
*SRE 128
To query the status byte enable register:
*SRE?
Related Commands
*ESE
*ESR?
*STB?
*STB?
Reads the condition register of the status byte register and returns a decimal value which
corresponds to the binary-weighted sum of all bits set in the register.
*STB?
Bit Weight 128 64 32 16 8
n.u. - Not Used
OPER - Operation Status Summary
MSS - Master Status Summary
RQS - Request for Service
ESB - Event Status Byte Summary
MAV - Message Available
QUES - Questionable Status Summary
Query? Yes
Set? Yes
Set/Return Parameters Integer (register binary value)
Minimum 0
Maximum 255
Units None
Query? Yes
Set? No
Return Parameters Integer (register value)
Minimum n/a
Maximum n/a
Units None
