Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide 175
Power Supply
Troubleshooting
12 ACOM ACOM ACOM ACOM ACOM ACOM
13 −7VA −7VA −7VA −7VA −7VA −7VA_SENSE
14 ACOM ACOM ACOM ACOM ACOM ACOM_SENSE
15 DCOM DCOM DCOM DCOM DCOM DCOM_SENSE
16 N.C. +12VD +12VD +12VD +12VD +12VD
17 DCOM DCOM DCOM DCOM DCOM DCOM_SENSE
18 +5.1VD +5.1VD +5.1VD +5.1VD +5.1VD +5.1VD_SENSE
19 DCOM DCOM DCOM DCOM DCOM DCOM
20 DCOM DCOM DCOM DCOM DCOM DCOM
21 +3.35VD +3.35VD +3.35VD +3.35VD +3.35VD +3.35VD
22 +3.35VD +3.35VD +3.35VD +3.35VD +3.35VD +3.35VD
23 FAN_P FAN_P FAN_N FAN_N PS_TEMP +5.1SB
24 N.C OFFn TEMP_SENSE PS_FAULTn PWR_OK PS_ONn
Table 8-3 Power Supply Connector Voltage Levels
Row A B C D E F
