Keysight Technologies N5166B CXG Service Guide

322 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Replacement Parts
Assemblies and Cables
Figure 14-20 A3 RF Assembly, A4 SSD, A5 CPU
Item Description Part Number
1 A3 RF Assembly see Table 14-3
2 A5 CPU Assembly and Thermal Pad N5180-60427
3 A5MP1 CPU Heatsink and Thermal Pad N5180-60443
4 Screw, machine, Pan Head, Torx T8, M2.5 x 0.45, 14 mm 0515-2141
5 Screw, machine, Flat Head, Torx T10, M3 x 0.5, 6 mm 0515-1227
6 A4 Solid State Disk Drive Assembly N5166B, N5172B, N5182B N5180-60426
