Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide 293
Replacement Parts
Assemblies, Cables, and Hardware
Rear Panel GPIB Connector A3 RF Assembly 2 0380-4993 Standoff M3 x 0.5
(17.5 mm)
7 mm 9 in-lbs
2 2190-0586 Lock Washer n/a n/a n/a
Rear Panel A3 RF Assembly 2 0515-1227 Flat Head M3 x 0.5
(6 mm)
T-10 9 in-lbs
1 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
A2 Vector BBG Assembly 4 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
Main Chassis 2 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
A1 Power Supply Assembly 1 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
Chassis Inner Top Cover 1 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
Chassis Inner Bottom Cover 1 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
A2 Vector BBG Assembly DIGITAL
BUS and AUX I/O Connectors
4 0515-0366 Pan Head M2.5 x 0.45
(6 mm)
T-8 6 in-lbs
A3 RF Assembly BNC Connectors 9 2950-0054 Hex Nut n/a 5/8" 21 in-lbs
9 2190-0068 Lock Washer n/a n/a n/a
A2 Vector BBG Assembly BNC
Connectors
8 2950-0054 Hex Nut n/a 5/8" 21 in-lbs
8 2190-0068 Lock Washer n/a n/a n/a
A7A1 ALC Control Z Axis Out 1 2950-0054 Hex Nut n/a 5/8" 21 in-lbs
1 2190-0068 Lock Washer n/a n/a n/a
Table 14-6 Attaching Hardware
Attach To Qty Part
Number
Type Size Tool Torque
