316 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Replacement Parts
Assemblies and Cables
W23, Coaxial Cable, A7A1 ALC Control J18 to A3 RF Assy J6000 8121-1578
W24, Semi-Rigid Cable, A7A2 20 GHz Multiplier J2 to A7A3
Mod-Filter J1
N5180-20209
W25, Semi-Rigid Cable, A7A3 Mod-Filter J2 to A7A5 Coupler Input
(513/520)
N5180-20285
W28, Semi-Rigid Cable, A7A5 Coupler Output to A7AT1 Atten Input
(513/520) (Option 1EM)
N5180-20284
W29, Coaxial Cable, A7A1 ALC Control J15 to A7A3 Mod-Filter J7 8121-1468
W30, Coaxial Cable, A7A1 ALC Control J16 to A7A3 Mod-Filter J6 8121-1468
W31, Coaxial Cable, A7A6 Detector Output to A7A1 ALC Control
J10 (513/520)
8121-2775
W32, Coaxial Cable, Rear Panel ALC IN to A7A1 ALC Control J12 8121-0859
W33, Ribbon Cable, A7A1 ALC Control J4 to A7AT1 P1 (Option
1EM)
N5180-60244
W34, Ribbon Cable, A7A1 ALC Control J5 to A7A2 20 GHz
Multiplier J3
N5180-60242
W35, Ribbon Cable, A7A1 ALC Control J8 to A7A3 Mod-Filter J10 8121-1469
Description Part Number
