Keysight Technologies N5172B EXG Service Guide

290 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide Replacement Parts Assemblies, Cables, and Hardware
Table 14-6 Attaching Hardware
Attach To Qty Part
Number
Type Size Tool Torque
A1 Power Supply Assembly Main Chassis 6 0515-1715 Pan Head M3 x 0.5
(40 mm)
T-10 9 in-lbs
A2 Vector BBG Assembly Main Chassis 4 0515-0374 Pan Head M3 x 0.5
(10 mm)
T-10 9 in-lbs
A2MP1 Connector Preload Bracket Main Chassis 2 0515-0666 Pan Head M3 x 0.5
(18 mm)
T-10 9 in-lbs
Cable Clamp, W6 to A2 Vector BBG Assembly A2 Vector BBG Assembly 1 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
A3 RF Assembly Main Chassis 10 0515-0664 Pan Head M3 x 0.5
(12 mm)
T-10 9 in-lbs
A3 RF Assembly Top Shield A3 RF Assembly Bottom Shield 29 0515-0383 Pan Head M4 x 0.7
(16 mm)
T-20 21 in-lbs
Cable Clamp, Rear Panel Output Cable (Option 1EM) A3 RF Assembly 2 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
A4 Solid State Disk Drive Disk Drive Bracket 4 0515-1946 Flat Head M3 x 0.5
(6 mm)
T-10 5 in-lbs
Solid State Disk Drive Interface Board Disk Drive Bracket 2 0515-0430 Pan Head M3 x 0.5
(6 mm)
T-10 9 in-lbs
Disk Drive Bracket A3 RF Assembly 4 0515-1227 Flat Head M3 x 0.5
(6 mm)
T-10 9 in-lbs
A5 CPU Assembly A3 RF Assembly 4 0515-2141 Pan Head M2.5 x 0.45
(14 mm)
T-8 6 in-lbs
A6 Front Panel Assembly Main Chassis 4 0515-5844 Flat Head M4 x 0.7
(8 mm)
T-20 21 in-lbs
A6A1, PCA, Front Panel Interface A6 Front Panel Assembly 7 0515-0372 Pan Head M3 x 0.5
(8 mm)
T-10 9 in-lbs
A6A2, USB Interface Assembly A6 Front Panel Assembly 1 0515-0374 Pan Head M3 x 0.5
(10 mm)
T-10 9 in-lbs
