318 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Replacement Parts
Assemblies and Cables
W21, Semi-Rigid Cable, A3 RF Assy J2004 to A7A2 20 GHz
Multiplier J1
N5180-20208
W22, Coaxial Cable, A3 RF Assy J7 to A7A1 ALC Control J11 8121-1468
W23, Coaxial Cable, A7A1 ALC Control J18 to A3 RF Assy J6000 8121-1578
W24, Semi-Rigid Cable, A7A2 20 GHz Multiplier J2 to A7A3
Mod-Filter J1
N5180-20209
W25, Semi-Rigid Cable, A7A3 Mod-Filter J2 to A7A4 40 GHz
Doubler J3 (532/540)
N5180-20211
W26, Semi-Rigid Cable, A7A3 Mod-Filter J4 to A7A4 40 GHz
Multiplier J1 (532/540)
N5180-20210
W27, Semi-Rigid Cable, A7A4 40 GHz Doubler J2 to A7A5 Coupler
Input (532/540)
N5180-20044
W28, Semi-Rigid Cable, A7A5 Coupler Output to A7AT1 Atten Input
(532/540)
N5180-20045
W29, Coaxial Cable, A7A1 ALC Control J15 to A7A3 Mod-Filter J7 8121-1468
W30, Coaxial Cable, A7A1 ALC Control J16 to A7A3 Mod-Filter J6 8121-1468
W31, Coaxial Cable, A7A6 Detector Output to A7A1 ALC Control
J10 (532/540)
8121-0900
W32, Coaxial Cable, Rear Panel ALC IN to A7A1 ALC Control J12 8121-0859
W33, Ribbon Cable, A7A1 ALC Control J4 to A7AT1 P1 N5180-60245
W34, Ribbon Cable, A7A1 ALC Control J5 to A7A2 20 GHz
Multiplier J3
N5180-60242
W35, Ribbon Cable, A7A1 ALC Control J8 to A7A3 Mod-Filter J10 8121-1469
W36, Ribbon Cable, A7A1 ALC Control J9 to A7A4 40 GHz Doubler
Control
N5180-60243
Description Part Number
